Position Configuration – NTRIP

Set up and configure NTRIP communications as either an NTRIP server or an NTRIP client. Set NTRIP to client for easy access to reference stations or network RTK corrections or set to Server for quick integration into GNSS infrastructure.

Refer to NTRIP Configuration for details on NTRIP overall configuration. Refer to the NTRIPCONFIG command for endpoint, port and type descriptions.

Server

Set to Server to define a Base.

Define the Endpoint, Correction Port and Correction Type. Once the Endpoint is entered, a drop list of the available Mountpoints in the network is automatically populated in the Mountpoint field.

Set to AUTO to use position averaging to automatically determine the position for a base station or set to FIXED to fix the position to help improve acquisition time and accuracy of position or corrections. The default setting is AUTO.

Once settings selected, press the APPLY button to save the changes or the CANCEL button to return to previous settings.

Client

Set to Client to define a Rover.

Define the Endpoint, Correction Port and Correction Type. Once the Endpoint is entered, a drop list of the available Mountpoints in the network is automatically populated in the Mountpoint field.

Once settings selected, press the APPLY button to save the changes or the CANCEL button to return to previous settings.
